SPECIFICATIONS OF ELITE 3000 OFFLINE UPS – 3000VA BLACK
Capacity: 3000VA
Green Power Function for Energy Saving
Microprocessor Controlled Guarantees High Reliability
AC Overload Protection
Wide Input Voltage Range (140~300VAC)
[vc_row][vc_column][vc_column_text]Output Short Circuit Protection · Intelligent Battery Management · Over Temperature Protection · Wide Range Of Input Voltage · Overload Protection · Auto Restart · Dataline Protection · Surge Protection · DC Start · Input Voltage: 220VAC · Input Frequency: 50Hz · Input Phase: Single Phase · Input Socket with FUSE · Cold Start (0~100% load): Press the ON / OFF Switch · Input Range (220V): 140V~285V · Normal Frequency:…
The 850va output Mercury Elite Pro Line Interactive UPS is a fairly robust unit for regular office or home appliances, including computers, printers, TVs, home entertainment systems, etc. The Mercury UPS range is trusted for superior performance, in the affordable price range.
The 1500va (1.5kva) output Mercury Elite Pro Line Interactive UPS is a fairly robust unit for regukar office or home appliances, including computers, printers, TVs, home entertainment systems, etc. The Mercury UPS range is trusted for superior performance, in the affordable price range.
The Mercury Elite 1500 Pro Line Interactive UPS is an advanced UPS design, with built-in AVR (automatic voltage regulator) to withstand the power voltage fluctuations that are common with our power supply.Other built-in protection measures to safeguard your appliances and also ensure the durability of the UPS include: overload protection, short-circuit protection, deep battery discharge protection and battery overcharge protection.
• Built-in AVR with wide input range of 140-300VAC
• Auto restart
• output short circuit protection
• Overload protection
• Overcharge protection
• Sleek and compact design with CPU control
• Back up time: Up to 18 mins.( depending on load)
Capacity3KVA / 2100WPhaseSingle PhaseInput voltage115VAC(±5) ~ 295VAC(±5) if load 70%Frequency46 ~ 54(50Hz)±0.5HzInput power factor0.97Output voltage220/230VAC ± 2%Frequency50Hz / 60Hz ± 0.2%THD< 3% (linear load)Overload capability> 110%, 30s turn to bypass mode; > 150%, 300ms turn to bypass modeCrest factor3:1 (max)Short circuit protection• 5 cycles turn off inverter, no transfer tp bypass, provide alarm (AC mode); • 5 cycles turn off inverter, provide alarm (AC mode); • Unput fuse blown or breaker action (bypass mode)WaveformPure sine waveTransfer time• 0ms between AC mode & Bypass mode • 4ms (typical 2.5ms) between Inverter mode & Bypass modeEfficiency85.00%Battery8x 12V / 7AHDC voltage96VDCBack-up16min (half load)Recharge time8hours ~ 90% capacityCharge current1A(standard unit)Communication interfaceRS232LED indicationLoad or battery capacityNoise level< 45dBTemperature0 ~ 40ËšCHumidity0% ~ 95% (non-condensing)Altitude< 1500mStorage temperature-25 ~ 55ËšCStandard unit (net/gross)34 / 36kgLong time unit (net/gross)15 / 17kgDimension (WxDxH)mm191 x 478 x 339mmModel12V sealed lead acid maintenance freePacking(WxDxH)mm332 x 603 x482
• Application: Small network, servers and other IT equipment • High frequency and double conversion on-line technology • Fully digitized microprocessor control • Wide input voltage range • LCD display • UPS startup without battery • Cold start • Advanced battery management • Automatic battery charge in UPS off mode • Lightning and surge protection • Short circuit and overload protection • Fan speed auto control when loads varies • Network/Fax/Modem surge protection • Optional extension battery pack • Battery voltage display • Load capacity display • EMI/RFI noise filter • Smart RS232 communication with monitoring software • Optional SNMP Card slot • EPO function(optional) • Input L and N reversed alarm function
[vc_row][vc_column][vc_column_text] Wide input voltage range Compatible with generators Overload protection Short circuit protection Built-in AVR Battery deep discharge protection & overcharge protection Rating input voltage: 2000 VA / 1200 W Rating input frequency: 60/50Hz (auto sensing) Input phase: Single phase Input socket: With Fuse Cold Start (0 to 100% load): Press the ON/OFF Switch Input…
